1530 Table Plasma and Flame Cutting Machine

1530 Table Plasma and Flame Cutting Machine，ApplicationMaterials: Stainlesssteel,mildsteel,brass,copper,aluminumalloy,sheetmetal,sprin gsteel,gold,silver,etc ApplicationIndustry: Sheetmetal,kitchenware,components,decorationsindustry

GET YOUR FREE QUOTE

12 Years Professional Laser Equipment Manufacturer

-Factory Direct & Fast Shipping

home / Products / Plasma Cutter / 1530 Table Plasma and Flame Cutting Machine

GET YOUR FREE QUOTE

1．seamless welding machine body

2．1500*3000mm working area

3．China LGK 63A Plasma source(Optional)

4．Independent control cabinet

5．STARfire control system

6．Automatic Torch height controller

7．Starcam software

8．2GB processing file

9．high precision square guide rail

10．high precision ball screw

11．China high precision stepper motor

12．Multi-function tool box

13．20 sets of nozzle electrodes

14．Two draught machines to remove smoke

15．Easy feeding slide material system

16．High quality soft electricity cable can be bend for 1.5 million times

17．All the necessary parts for machine working

Technical Parameters

Model	1530 63A Plasma cutting machine (high configuration)
X,Y working area	1500*3000mm
Z working area	150mm
Packing dimension	2280mm3850mm1850mm
Lathe bed	Very thicksteel structure
Machine Power	8.5kw
Working voltage	380V three phase 60hz
Reposition precision	0.02mm
Processing precision	0.1mm
Maximum cutting speed	12000mm/min
Torch Height control mode	Automatic
Cutting thickness	Max 12mm carbon steel
Plasma power supply	LGK63A
Control system	STARfire
Motors	Stepper motor
Software	Starcam
Weight	1600KG
Plasma Air Pressure	Max.0.8Mpa
Working Temperature	-10°C-60°C. Relative Humidity, 0-95%.
LCD Display Dimension	7Inches
